- Ideal for wide measurement up to AC/DC 400A.
- Suitable for current management in distorted circuits with waveforms, such as inverters.
- Easy zero adjustment in DC current measurement with a single push.
Specifications
| Measuring range | AC Current AC 40A/400A DC Current DC 40A/400A AC Voltage AC 600V DC Voltage DC 600V Resistance 1000Ω |
|---|---|
| AC current accuracy | 40A range ±1.5%rdg±5dgt 400A range ±1.5%rdg±8dgt |
| DC current accuracy | 40A range 1.5%rdg±3dgt 400A range 1.5%rdg±5dgt |
| CT Inner Diameter | φ30mm |
| Minimum resolution | 0.01A |
| Other features | Data Hold, Auto Power Off, One-Push 0 Adjustment, RMS |
| power | AA alkaline battery×3 |
| Dimensions and Weight | W45×H180×D24mm Approx. 135g |
| accessory | Batteries, soft cases, test leads |
