- Accurate measurement even when solar panels are generating electricity.
- Safe operation without the need to short-circuit the P-N phase.
- Can measure AC voltage from 0 to 599V.
- Can be used in AC circuits.
- Suitable for both low-voltage circuits and equipment as well as solar power applications, all in one unit.
Specifications
| Rated Measurement Voltage | 125V | 250V | PVL（500V） | PVH（1000V） |
|---|---|---|---|---|
| Maximum effective display value | 20MΩ | 50MΩ | 100MΩ | 2000MΩ |
| Median display | 0.5MΩ | 1MΩ | 2MΩ | 50MΩ |
| First effective measurement range | 0.02MΩ～10MΩ | 0.05MΩ～20MΩ | 0.1MΩ～50MΩ | 2MΩ～1000MΩ |
| Tolerance | ± 5% RDG or less | |||
| 2nd effective measurement range | 0.01MΩ～0.02MΩ | 0.02MΩ～0.05MΩ | 0.05MΩ～0.1MΩ | 1MΩ～2MΩ |
| 10MΩ～20MΩ | 20MΩ～50MΩ | 50MΩ～100MΩ | 1000MΩ～2000MΩ | |
| Tolerance | ± 10% RDG or less | |||
| AC voltage measurement range | AC0~599V (minimum resolution 0.1V) |
|---|
| indication | 3200 count LCD and bar graph display |
|---|---|
| Viewing range | 3. 200MΩ / 32.00MΩ / 320.0MΩ / 3200MΩ (4 Range Auto) |
| Minimum resolution | 0.001MΩ |
| Other features | Overrange display, data hold, auto power off, backlight, automatic load discharge function |
| standard | JIS C 1302(2002) compliant |
| Operating temperature and humidity range | 0~40°C, 80%RH or less (no condensation) |
| power | AA alkaline battery×6 |
| Dimensions and Weight | W170×H52×D105mm Approx. 350g |
| accessory | Battery, measuring cord set, insulating cap (red), belt, carrying case |
| option | Probe with switch (cord length approx. 1m) (MP-001) ¥3,200 (excluding tax) Capacitive countermeasure cord (MC-001) ¥5,400 (excluding tax) |
