Product specification

Bracket code	Wheel sizeDmm	Mounting heightHmm	Top plate AxBxCmm	Mounting pitch XxYxZmm	Mounting hole ∅ Pmm	Offset Emm	Swivel radius mm	Wheel fixing
220 SOE	85	103	160x63x58	139x55x42	8.8	28	72	Nut
	100	122	160x63x58	139x55x42	8.8	32	83	Nut
	125	148	160x63x58	139x55x42	8.8	39	103	Nut
215 SOE	85	103	160x63x58	139x55x42	8.8	28	74	Nut
	100	122	160x63x58	139x55x42	8.8	32	83	Nut
	125	148	160x63x58	139x55x42	8.8	39	103	Nut

Product code			Load capacity	Wheels	Wheel code			Tread width mm
Bracket code	– Wheel type	Size	Load capacity	Wheels	Wheel number	– Type	Size	Tread width mm
220 SOE 215 SOE	– R	85	50	Rubber Solid type + bushing *Customize: conductive \| P27	425 E	– R	85	27
		100	50				100	27
		125	60				125	27
220 SOE 215 SOE	– RN	85	50	Rubber Nylon hub *Customize color: black	425 E	– RN	85	27
220 SOE 215 SOE	– RN	100	50	Rubber Nylon hub *Customize color: black	425 E	– RN	100	27
220 SOE 215 SOE	– N	85	60	Nylon Solid type Customize color: grey / black Customize: conductive \| P27	429 E	– N	85	25
		100	60				100	25
		125	70				125	25
220 SOE 215 SOE	– UR	85	60	Urethane \| Thermoplastic Nylon hub + bushing *Customize: antistatic \| P27	439 E	– UR	85	27
		100	60				100	27
		125	70				125	27
220 SOE 215 SOE	– UB	85	60	Urethane \| Thermoplastic Nylon hub + roller bearing For stainless steel caster Customize: antistatic \| P27	439 SOE	– UB	85	27
		100	60				100	27
		125	70				125	27
220 SOE 215 SOE	– L	85	50	Elastomer PP hub	429 E	– L	85	27
220 SOE 215 SOE	– L	100	50	Elastomer PP hub	429 E	– L	100	27
220 SOE 215 SOE	– MC	100	60	MC Nylon Solid type	499 E	– MC	100	25
220 SOE 215 SOE	– MC	125	70	MC Nylon Solid type	499 E	– MC	125	25
